| Standard: | AHD, HD-CVI, HD-TVI, PAL |
| Video inputs: | 16 pcs BNC – HD-TVI / AHD / HD-CVI / CVBS |
| Video outputs: | 1 pcs HDMI 1 pcs VGA |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | H.264 / H.264+ |
| Number of compression levels: | 6 |
| Image records resolutions: | 960 x 1080 – 1080N 1280 x 720 – 720p 960 x 576 – 960H 704 x 576 – 4CIF 640 x 480 – VGA |
| Maximal total frame rate: | 400 fps @ 960 x 1080 px, 400 fps @ 1280 x 720 px, 400 fps @ 960 x 576 px 400 fps @ 704 x 576 px 400 fps @ 640 x 480 px |
| Recording speed adjustment: | 1 … 25 fps @ 960 x 1080 px 1 … 25 fps @ 1280 x 720 px 1 … 25 fps @ 960 x 576 1 … 25 fps @ 704 x 576 1 … 25 fps @ 640 x 480 px for each channel |
| Operation modes: |
All modes allow for any combination of the AHD-H, HD-CVI, HD-TVI, PAL cameras |
| Recording modes: | Manual, Motion Detection, Schedule |
| Supported hard drives: | 1 x 6 TB SATA |
| External storage devices backup: | Backup to USB drive (pendrive) |
| Searching and playback the records: | Records searching: timeline or file list. Playback: forward, fast, slow. Playback max. 16 cameras in the same time |
| Network interface: | 1 x RJ-45 – 10/100 Base-T |
| Network functions: | Network Client Software and IE browser: live view, playback and backup of the records, partial configuration of the recorder parameters |
| Bitrate: | 32 … 4096 kbps |
| Network protocols: | TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS |
| Default IP address: | DHCP or 192.168.1.64 |
| Web browser access ports: | 80 |
| PC client access ports: | Port no.: 8000 or access by a cloud (P2P) – iVMS-4200 application |
| Mobile client access ports: | 8000 |
| Port ONVIF: | 80 |
| PTZ control: | Control compatible with coax HD-TVI Hikvision |
| Motion Detection: | Split the screen into zones : 22 x 18 motion zones |
| Power supply: | 12 V DC / 2 A (power adapter included) |
| Color: | White |
| Weight: | 0.94 kg |
| Dimensions: | 283 x 219 x 47 mm |
